Integrated Lithium Auxiliary Battery Kit by Cangoee – Toyota LandCruiser 300 Series MY23

AUD $4,410.00 (Excl. Tax AUD $4,009.09)

In stock

To Suit

  • Toyota LandCruiser 300 Series (no subwoofer)
(Ships directly from the supplier)
Brands:
SKU: KIT10030
Cangoee

Cangoee Lithium Integrated Auxiliary Battery Kit to suit Toyota LandCruiser 300 Series MY23 (no factory subwoofer)

Cangoee Australia has been part of a group of companies designing and manufacturing sophisticated technology solutions for the Emergency Services market for over 20 years.

Cangoee’s technology and build quality have been trusted by Australia’s emergency services, from the police, ambulance and fire services to Telstra, Australia’s largest telecommunication company, proving their quality and performance in the most demanding environments and applications.

Cangoee has now expanded its range of products into the 4WD and camping markets by releasing a fully integrated auxiliary or secondary battery kit designed as an accurate, complete plug-and-play solution.

One of the key advantages of the Cangoee lithium dual battery kit is the significantly reduced installation time from the typical 10-12 hours to under 2 hours, depending on the vehicle model, providing a cost-effective solution and saving on expensive labour costs.

The Toyota LandCruiser 300 unit comes equipped with an internal BMS (battery management system), a 20-amp dual-stage DC/DC charger, and solar power charging, providing up to 100 amps of continuous discharge and 100 amps of rapid charge.

Installation is made easy using existing factory OEM mounting points for mounting the kit. The wiring is pre-configured as a plug-and-play system eliminating any need for cutting or tapping into the factory wiring.



Charging

The DC-DC charger in the CAN battery allows the Dual Lithium battery to charge from a vehicle engine/alternator/start battery. However, to avoid draining the start battery, charging is only performed while the engine is running.



Features

  • Designed, engineered, and assembled here in Australia
  • Proven reliability to withstand the harshest Australian conditions
  • No Cutting is required for installation
  • Easy Install (No drilling required, Utilises OEM mounting points, Plugs directly into factory wiring loom)
  • Twice the capacity of AGM/ SLA batteries, 50% lighter than other systems
  • Internal monitoring system for optimised performance
  • Ignition Trigger for smart alternators
  • Inbuilt Victron Energy Smart Shunt for battery and load monitoring (via Bluetooth)
  • Robust Aluminium case
  • Simultaneous charging – DC/DC and solar for fast charging
  • Inbuilt Victron Energy MPPT (Maximum Power Point Tracking) Solar Controller (monitoring via Bluetooth)
  • DC/DC battery charger 20A
  • Inverter Ready
  • Bluetooth Connectivity
  • Full OE standard vehicle looms
  • ISO 9001:2015 quality standards



Installation

  • Installs behind the Left Hand Side Rear Quarter Panel using factory mounting points
  • Installation Time – Approx 2 hours



Warranty

  • 5-year Warranty



Accessories Power Outlets

  • 1 x Anderson Plugs – Grey (50A)
  • 1 x Anderson Plug – Grey ( 175A) Inverter



Accessories Power Inlets

  • 1 x Anderson Plug – Red (Solar Power)



Other Anderson Connectors

  • 1 x Anderson Plug – Blue (DC-DC and Main Negative)



Specifications

  • 110Ah Lithium (LiFePO4) Capacity
  • 120A BMS (Battery Management System)
  • Charge Current – 120A
  • Discharge Current – 120A
  • PV (solar photovoltaic) capacity 220W
  • Life at 80% DoD – 2000 cycles
  • Life at 50% DoD – 5000 cycles
  • Weight 17.5kg



Kit Includes

  • Part Number KIT10030
  • 1 x Powermate 110Ah Lithium Battery
  • 1 x DC-DC Charge cable
  • 1 x Ignition sense Fuse and harness
  • 1 x Mid Fuse on bracket
  • 1 x Positive battery connection
  • 1 x Installation Guide



Cangoee Integrated Vehicle Dual Battery Kits

Available Now

  • MY21 Nissan Y62 Patrol
  • MY21 Ford Ranger
  • MY21 Isuzu D-Max
  • Toyota LandCruiser 300 Series

Coming Soon

  • MY21 Isuzu MUX
  • MY21 Toyota Hilux
  • Toyota Landcruiser 70 Series
  • Nissan Navara
  • Mitsubishi Triton
  • Volkswagon Amarok



To Suit

  • Toyota LandCruiser 300 Series (no factory or removed subwoofer)
